Forklift lithium ion battery 48v 400Ah 420Ah 450Ah 500Ah 600Ah

Inquire Now

Features

Brand: NOVACELL
Model: NV-FL48V460Ah
Anode: LiFePO4
Voltage: 48V/51.2V
Capacity: 460Ah
Working temp.: 0~55℃
Weight: 290KG
Dim.: 1228*347*784(mm)

Advantage

Maintenance: 0
Rapid charge: 2.5Hrs
Cycle life: 4000+ cycles
Warranty: 5 years
Quality: Grade A
Design Life: 10+ years
IP Rate: IP65
Certificate: CE RoHS UN38.3

Application

Forlift
Clark forklift
Toyota forklift
Komatsu forklift
2.0t heli forklift
Hangcha forklift
Tcm forklift
Doosan forklift

Specification

Electrical Characteristics	Voltage	48V
	Nominal Voltage	51.2V
	Nominal Capacity	460Ah
	Energy	23.55kWh
	Battery type	LiFePo4
	Cycle Life	4000+ cycles
	Months Self Discharge	≤3% per month at 25℃
Standard Charge	Charge Voltage	58.4±0.2V
	Charge Mode(CC/CV)	At 0℃~45℃, charged to 58.4V at constant current of 0.2C5A, and then change continuously with constant voltage of 58.4V until the current was not more than 0.02C5A.
	Standard Charge Current	200A
	Max.Charge Current	200A
Standard Discharge	Standard discharge Current	350A
	Max. Discharge Current	350A
	Peak Discharge Current	700A(30S)
	Disxcharge Cut-off Voltage	40.0V
Environmental	Charge Temperature	0℃~45℃
	Discharging	-10℃~60℃
	Storage temperature	-5℃~35℃
	Storage Humidity	≤75% RH
	Water Dust Resistance	IP65
Mechanical	Cell	16S2P
	Housing	SPCC
	Dimension(LWH*)	1228347784(mm)
	Communication interface	RS485 / CAN
	IP Rate	IP65
	Weight	Approx. 290Kg

Related Models

Voltage	Nominal Voltage	Capacity	Energy	Cycle life	Dimension(mm)	N.W.	Charge current	Discharge Current	Peak current	Housing	IP rate
24V	25.4V	105Ah	2.68kWh	4000+ Cycles	635180538mm	50KG	50A	100A	300A(30S)	SPCC	IP65
		150Ah	3.84kWh		635180538mm	60KG	50A	100A	300A(30S)	SPCC	IP65
		173Ah	4.42kWh		625210630mm	80KG	80A	160A	480A(30S)	SPCC	IP65
		210Ah	5.37kWh		630295290mm	50KG	70A	200A	300A(30S)	SPCC	IP65
		280Ah	7.16kWh		655250574mm	80KG	200A	200A	300A(30S)	SPCC	IP65
		315Ah	8.06kWh		645240520mm	100KG	100A	250A	400A(30S)	SPCC	IP65
36V	38.4V	420Ah	16.12kWh	4000+ Cycles	776360610(mm)	200 KG	120A	300A	450A(30S)	SPCC	IP65
36V	38.4V	840Ah	32.25kWh	4000+ Cycles	983521782(mm)	400 KG	200A	300A	450A(30S)	SPCC	IP65
48V	51.2V	210Ah	10.75kWh	4000+ Cycles	800365410(mm)	135 KG	105A	210A	500A(30S)	SPCC	IP65
		230Ah	11.77kWh		8650300550(mm)	370 KG	200A	350A	500A(30S)	SPCC	IP65
		280Ah	14.33kWh		780425475(mm)	180 KG	140A	280A	500A(30S)	SPCC	IP65
		315Ah	16.12kWh		970460740(mm)	230 KG	157A	350A	500A(30S)	SPCC	IP65
		460Ah	23.55kWh		1228347784(mm)	290 KG	200A	350A	700A(30S)	SPCC	IP65
72V	73.6V	420Ah	2.68kWh	4000+ Cycles	800370570(mm)	410 KG	200A	350A	700A(30S)	SPCC	IP65
		460Ah	3.84kWh		1228347784(mm)	420 KG	200A	350A	700A(30S)	SPCC	IP65
		560Ah	4.42kWh		1028570780(mm)	500 KG	200A	350A	700A(30S)	SPCC	IP65
80V	80V	460Ah	36.8kWh	4000+ Cycles	1075995495(mm)	1300 KG	150A	300A	450A(30S)	SPCC	IP65
80V	80V	560Ah	44.8kWh	4000+ Cycles	1145680790(mm)	1300 KG	300A	300A	450A(30S)	SPCC	IP67

More details

Forklift lithium ion battery 48v 400Ah 420Ah 450Ah 500Ah 600Ah for heli is Lithium battery that
replace for lead acid forklift battery, this battery is equipped with smart battery management system, this battery has features of long life span, zero maintenance, fast charge and cost effective
